  • 11002

    Standard 1 Module 24 hr Timer

    • Simple programming with 15 min captive segments
    • Simple to read switching
    • Manual override switch "Permanent OFF/Automatic/Permanent ON"
    • 100 hour battery reserve

Technical Specifications

Power Supply 230V AC, 50/60Hz
Mounting DIN
Current Rating16A, 2.5amp Inductive @0.6pf
Switching Capacity Filament lamp Halogen lamp 2,000W Fluorescent lamp uncompensated 1,000W Fluorescent lamp series compensated 750W LED (230 V~) / CFL 200W
Reserve100 hrs
Switching Functions ON, OFF, Permanent On/Off
Switching Operation96 per day
Program Security unlimited (E2-PROM)
Minimum Interval15 min
Temperature Range-5°C to +50°C
Enclosure Self-extinguishing thermoplastic
Type of Protection IP20 to DIN EN 60529
Dimensions65 x 18 x 90 mm
